Reel Rewinding Station
Print Inspection System
Hot Air Dryer
4 Color Printing Station
Reel Unwinding Station
-
Max. Speed
200 Meters/Minute
-
Automatic Reel To Reel Flexo Printing Machine
- STM 125 E
STM 125 E includes a Reel Unwinding Station, a six-color Printing station ( 6C Printing on One Side), a Hot Dryer Un, a Reel Rewinder station, and control components.
Request a Quote
Download Brochure
- Paper Bag Manufacturer
- Flexo / Half Tone Printing Application
- Reel to Reel Paper Printing
- Reel to Reel Cup Stock Printing
- Accurate color registration
- Pneumatic cylinder lifting arrangement to stir the ink
- Hot air drying system to dry the ink at high speed
- Able to print large repeats
- Sutaible for printing of kraft papper, rolling paper, packing paper & glass paper
- Two Color Printing On Both Side
- Ceramic Coated Anilox Roller
- Doctor Blade Chamber System
- Print Inspection System
Technical Specification
| Model | STM 125 E |
|---|---|
| Web Speed* (meters/minute) | 200 |
| Reel Width (mm) | 290 to 1250 |
| Reel Diameter (mm) | 550 to 1300 |
| Reel Weight (kgs.) | 1400 |
| Core ID (mm) | 76.2 |
| Printing Width (mm) | 1200 |
| Repeat Printing Width (mm) | 340 to 1200 (Variation of 5mm) |
| Paper GSM | 45 to 300 |
| Rec. Floor Space (L x W x H) (meter) | 11 X 7 X 4 |
| *Machine Speed depends on Print length & Print area on web. | |
